56

Legend for chart above:
A Semiautomatic system; manual dispensing start
and stop.
B Automatic system; electronic control of coffee
and hot water doses dispensed.
C Number of group heads
Number of steam wands
E Number of water spouts
F Operating with economizer.
Gas heating, on request.
1 Steam tap
2 Steam wand
3 Function/service push-button panel
4 Hot water switch
5 Group head
6 Coffee dispensing push-button panel
(mod.S - E)
7 Manual water supply tap
8 Level indicator
9 Gauge
10 Power on-off switch and LED
11 Gas lighter (on specic models)
12 Valved gas tap (on specic models)
13 Switch and boiler heating element light
engagement light.
14 Programming panel (mod. E)
15 Hot water spout
16 Group head control lever (mod.L)
17 Cup heating element switch

The machines in the CLASSE 6 series have been
designed to prepare espresso and other hot beve-
rages.
A positive-displacement pump inside the machine
powers the boiler. With the push of a button water
or steam is supplied to the outlets, depending on
your needs.
The hot water used to make drinks comes from the
boiler.
The machine is composed of a steel frame on whi-
ch the mechanical and electrical components are
mounted. The side panels are made of aluminum.
The beverages are dispensed at the front of the
machine, where all the buttons, control devices and
dispensers are to be found.
There is a cup-warming plate on the top of the ma-
chine.
 (Fig.3)
Models equipped with gas connections (when applied).


GROUPS
 
 1 1 1 1
 1 2 3 4
Filters 2 3 4 5
 1 1 1 1
 1 1 1 1
 1 1 1 1
Pipe connections 1 1 1 1
Blind disks for cleaning 1 2 3 4
Plastic scoop and tamper 1 1 1 1
Instruction manual 1 1 1 1
Brush 1 1 1 1
A B C E

- ok 2 - 3 2 1

ok - 2 - 3 2 1

ok - 1 - 2 - 3 - 4 2 1
