OPERATION
(Fig.8)
Two-position switch with LED..
Turn on the switch (LED. on) the machine is turned
(apart from the boiler) and the pump is turned on
to ll the boiler;
Two-position switch with LED.
Upon activating the switch (LED on) the power is
supplied to the heating elements in the boiler. .
Two-position switch with LED
By turning on the switch (LED on), the power is
supplied to the cup warmer heating element.
(mod.S)
Two-position switch:
With switch ON, coffee is dispensed;
With switch OFF, dispensing of coffee is interrupted.
(mod. E)
Five buttons with corresponding LEDs:
A Press the button for a second, LED on, release
button; a small coffee is dispensed.
The LED turns off and dispensing stops.
B Press the button for a second,LED on, release
the button; two small coffees dispensed from the
same unit.
The LED turns off and dispensing stops.
C Press the button for a second, LED on, release
the button; a big cup of coffee is dispensed.
The LED turns off and dispensing stops.
Press the button for a second, LED on, release
the button; two big cups of coffee are dispensed
from the same unit.
The LED turns off and dispensing stops.
E Press the button for a second, LED on, release
the button; coffee is continuously dispensed.
Press the button for a second, LED off, release
button; continuous dispensing of coffee stops.
To interrupt brewing once the operation has been
activated with buttons , press the same
button again or press E.
(mod.L)
The lever is usually placed in an upward posi-
tion.
Activate the lever by pushing it down to obtain
coffee dispensing.
(mod.S)
Hot water switch with two positions:
With switch ON, the LED ashes and hot water is
dispensed directly from the boiler.
With switch OFF, the LED switches off and dispen-
sing stops.
(mod.E)
When the button is pressed, hot water is dispensed
up
● Position the machine unit onto the horizontal sur-
face provided for that purpose and adjust the base
feet to ensure that the machine is stable and that
vibrations are limited.
Before connecting the machine, thoroughly ush the
main water supply pipes:
● Open the main water supply taps and let the water
run at full pressure for several minutes.
● Connect to the main water supply.
● Connect the machine up to the power supply
mains.
● Connect the gas pipe.
Thoroughly ush all the water pipes of the machine:
● Leave the water supply taps running at full pres-
sure.
● Switch on main switch 1 (Fig.8): wait until the boiler
lls up to the set level.
● Switch on boiler heating element switch 2 (Fig.8)
to begin heating the water in the boiler.
● Once standard machine work conditions have been
reached with the machine in “ready for operation”
mode, switch the machine off and empty all the wa-
ter lled into the water circuit the rst time, thereby
eliminating any possible initial impurities.
● Fill the machine up with water again and set it into
standard operation mode.
● Once the “ready for operation” status is reached:
- Connect the lter-holders to the dispenser units
(without coffee); operate each group head in
order to allow the water to escape for about one
minute.
- Dispense hot water until at least 2 liters of water
have been dispensed from the 1-group or 2-groups
compact, 5 liters from the 2-groups machines, 8
liters from the 3-groups machines and 11 liters
from the 4-groups machines.
- Open each steam dispensing point for 1 whole
minute.
Once installation is terminated, the installa-
tion technician MUST issue an installation
report.
