GB
Page 4 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R
KEY
1 – Weight holding bridge
2 – Pneumatic mandrel (only for GP3.140R - GP3.140RS models)
3 – Distance-diameter caliper
4 – Threaded mandrel (only for G3.140R - G3.140RS models)
5 – Protection guard
6 – Foot brake (only for G3.140R - G3.140RS models) / pneumatic mandrel open-close pedal (only for
GP3.140R - GP3.140RS models)
7 – Main switch
8 – External data gauge (standard for G3.140RS - GP3.140RS models ) (optional for G3.140R - GP3.140R
models)
9 – Fixed laser unit + led light (standard for G3.140RS - GP3.140RS models)
10 – Monitor
11 – Pusher ring
12 – Rapid ring nut (only for G3.140R - G3.140RS models)
13 – Locking sleeve (only for GP3.140R - GP3.140RS models)
14 – Cones
15 – Professional external data gauge (optional)
16 – Grippers for weight fitting
17 – Lateral guard
18 – Push-button panel with 7 keys
Fig. 1 - G3.140R - GP3.140R - G3.140RS - GP3.140RS
