- Turn manually the wheel until you have the weight of
100 g on the outer side at "12 o'clock".
- Press the brake pedal and hold it down during the
whole the following operation to avoid unexpected
rotation of the spindle.
- Remove the weight from 100 g from the outside of the
wheel and apply it on the inner side at "12 o'clock".
- Close the guard to perform the 3rd spin of the wheel
(100 g weight placed on the inside wheel).
At the end of the rotation, the video screen below will
be displayed to indicate that the operation is finished.
1 2
KEY
1 – Distance-diameter caliper calibration
2 – External data gauge calibration
Distance-diameter caliper calibration
Press the button to display the following screen
page on the monitor:
APPLY THE WEIGHT AT A POINT
IN WHICH BOTH SIDES OF THE
RIM THERE IS THE POSSIBILITY
OF APPLYING A CLIP WEIGHT OF
100 g.
- Apply the weight and position it perfectly to the "12
o'clock".
- Press the button and close the guard to per-
form the 2nd spin of the wheel (100 g weight placed
on the outside of the wheel).
- At the end the following screen will appear on the
monitor, suggesting to remove the weight of 100 g
previously applied on the outer side and apply it on
the inside of the rim.
WHEN THE OPERATION IS CON-
CLUDED, REMOVE THE WHEEL
FROM THE MANDREL AND PER-
FORM A COMPLETE CALIBRATION
PROCEDURE Ø MANDREL AS DE-
SCRIBED IN PAR. 15.2.1.
15.2.3 Gauge calibration
Press the button to display the following screen
page on the monitor:
