INSTRUCTION MANUAL
RAV TD8060TWS - RAV TD8060TWSR
RAV TD8080TWS - RAV TD8080TWSR
Code M0230 - rev.1.1
(01/2014)
RAVAGLIOLI S.p.A.
RAVAGLIOLI S.p.A. – 40044 Pontecchio Marconi (BO) Via I Maggio, 3
Page 9/ 64
Tel. (+39) 051/ 67.81.511 – Fax (+39) 051/ 84.64.67
e-mail: rav@ravaglioli.com /http www.ravaglioli.com
3.7.1 Sensors TD8080TWSR and front RAV TD8060TWSR
Figure 2
3.7.2 Sensors RAV TD8080TWS and front sensor RAV TD8060TWS
Figure 3
SENSOR KEYBOARD
(see para. 3.7.4 on page 10)
CONNECTOR FOR
CALIBRATION CABLE
ADJUSTMENT TOLERANCE
INDICATION LED
(see para. 3.7.4 on page 10)
GREEN INDICATOR LED  SENSOR
UNDER CHARGE.
RED INDICATOR LED

SENSOR ON
SENSOR KEYBOARD
(see para. 3.7.4 on page 10)
CONNECTOR FOR
CALIBRATION CABLE
ADJUSTMENT TOLERANCE
INDICATION LED
(see para. 3.7.4 on page 10)
BATTERY HOUSING
GREEN INDICATOR LED  SENSOR
UNDER CHARGE.
RED INDICATOR LED

SENSOR ON
BATTERY HOUSING
