016-4010-001 Rev. J 59
DIAGNOSTICS AND TROUBLESHOOTING
FIGURE 6. Diagnostic Trouble Codes Page
NOTE: In Figure 5 on page 58 above, the active DTC is 522250.31 and the DTC summary is “No Guidance
Points.” The inactive DTC is 522261.31 and the DTC summary is “No SCU Detected.”
FIGURE 7. Info Page
Pressing the Info button displays the complete description of the highlighted active DTC.
FIGURE 8. Inactive DTCs Cleared from Error Log
Diagnostic
Trouble Code
(DTC)
DTC Summary
To Next Page
