CHAPTER 9
52 Raven RS1™ and RS Lite™ Calibration and Operation Manual
STARTING A JOB
Refer to the ROS (Raven Operating System) Basic Operation Manual (P/N 016-0171-539) for instructions on starting
a job and setting guidance lines.
ENGAGE STEERING
FIGURE 1. RS1 Status Widget on ROS
NOTE: If the steering widget does not appear on the screen, refer to the Viper/Viper 4+ Installation and
Operation manual (P/N 016-0171-539) for further information on adding widgets.
NOTE: The operator liability waiver must be accepted before the RS1 system can be enabled for operation.
The RS1 steering may also be engaged using the following methods:
• Tap the foot switch or rocker switch to engage RS1 features during field operation.
• Press the RS1 on-screen status widget to engage the RS1 during field operation.
UPDATING RS1
Refer to the Field Updates section on page 101 or the field computer manual for instructions on updating the RS1
software.
