CHAPTER
10
016-4010-001 Rev. J 53
CHAPTER 10
DIAGNOSTICS AND
TROUBLESHOOTING
BUTTON DEFINITIONS
STEERING STATUS
FIGURE 1. Home Page
The following are common steering status or mode messages which may occur while the RS1 system is engaged:
Display Message
Active diagnostic and troubleshooting codes are present. The RS1 system cannot
be engaged in this state.
Active diagnostic and troubleshooting codes are present. The RS1 system can be
engaged in this state, but performance quality may be degraded.
No active diagnostic or troubleshooting codes are present. The RS1 system is
ready to be engaged.
NOTE: Both the steering wheel and GPS icons must be green in order to
engage the RS1 system.
Steering is engaged, with no active diagnostic or troubleshooting codes present
in the RS1 system.
