Raven SCS 460 - Other Display Features; Self Test Feature

18
2. OTHER DISPLAY FEATURES
1) To display TOTAL AREA covered, momentarily depress .
To "zero out" this total at any time, enter a "0" in this key.
2) To display TOTAL VOLUME sprayed, momentarily depress .
To "zero out" this total at any time, enter a "0" in this key.
3) To display FIELD AREA covered, momentarily depress .
To "zero out" this total at any time, enter a "0" in this key.
4) To display FIELD VOLUME sprayed, momentarily depress .
To "zero out" this total at any time, enter a "0" in this key.
5) To display DISTANCE (feet) [meters] traveled, momentarily depress . To "zero out" this total
at any time, enter a "0" in this key.
6) To display SPEED, momentarily depress .
7) To display VOL/MIN, momentarily depress .
8) To display AREA/HOUR, momentarily depress . This is an actual calculation of
AREA/HOUR at the present speed you are going. It is not an average over a period of time.
9) To display US, SI, or TU; SP1 or SP2; and C-SD, C-F, C-FC, C-P or C-PC after being selected,
depress .
3. SELF TEST FEATURE
SELF-TEST allows speed simulation for testing the system while vehicle is not moving. Enter the
simulated operating speed in . If 6 MPH [10 km/h] is desired, enter 6.0 [10.0]. Verify SPEED
by depressing . The SELF-TEST speed will clear itself when motion of vehicle is detected
by the Speed Sensor. A SPEED CAL value of 900 [230] or greater is recommended when operating
in this mode.
NOTE: To prevent nuisance clearing of self-test speed, disconnect speed connector on
back of Console when Radar Speed Sensors are used.
