20
9. ZERO SPEED SHUT-OFF
This function will be active when C-FC (Fast Close Valve) or C-PC (PWM Close Valve) is selected.
This function can not be disabled. When C-FC or C-PC has been selected, the valve will receive
a decrease signal and run closed when the speed drops to .7 MPH or less. The only way the console
can operate at .7 MPH or less is in the manual mode.
When a zero speed shut-off has occured, the MASTER switch must be turned OFF and then ON
to restart the system. If a constant speed greater than .7 MPH is not attained within 10 seconds,
the zero speed shut-off will be enacted again.
10. DATA MENU
The following are brief descriptions of features available under the DATA MENU key.
DISPLAY DESCRIPTION
PRINT FIELD BEGIN Sends data through serial port to attached optional printer to
print field begin and field end pages.
ALARM ON Turns audible alarms ON or OFF for the following:
1) Volume/Area Rate Alarm
2) Volume/Minute Rate Fault
3) Low Tank Fault
DISPLAY SMOOTHING ON Turns display smoothing ON or OFF. Selecting display
smoothing ON means the window displays target rate when
actual rate is within 10% of target rate.
RATE CHANGE ALARM ON Turns rate change alarm ON or OFF. When rate change
alarm is selected ON; alarm sounds 4 long beeps when the
Rate 1 calibration number is changed via the serial port using
a valid change request data string.
GPS FILE REF 1 Used only with Raven Grid Application System. See Grid
Application System manual for more details.
GPS INACTIVE Used only with Raven Grid Application System. See Grid
Application System manual for more details.
FIELD REF 0 Allows user to enter up to a four-digit number to represent a
field. Field reference is included in field begin and field end
pages and the data logger time/date string.
BAUD RATE 9600 Used in GPS mode and data logging mode. Selectable
between 1200 or 9600 baud.
DATA LOG TRIGGER VALUE 0 Used in data logging mode. The trigger determines how
often actual rate data string (See Appendix 10 for Data
Communication String Formats) is sent to the serial port. The
trigger may be either feet [meters] or seconds.
