Overview of Cable Connection & Routing
Before starting the Cable Connection and Routing section of this document you should first ensure
that all components of the hydraulic steering kit are installed securely and neatly.
The cable connection and routing instructions that are included in this section consists of:
• Smartrax Loom connection and routing;
• Solenoid cable connection and routing
• Steering Position Sensor (SPS) cable connection and routing.
NOTE: The Cable Connection & Routing section of this manual is generic and has been
designed to cover all tractor types currently available.
