7
Safety Warning Labels
Safety Warning Labels have been provided to highlight to users the importance of:
• Being aware not to damage the wheel angle sensor.
• Not tampering with the SmarTrax hydraulics valves.
These warning labels are to be placed in the specified locations as indicated below.
Steering Position Sensor Warning Label
It is essential that the Steering Position Sensor (SPS) is not damaged. Therefore Raven Industries
has provided a ‘Do Not Step’ warning label. This label is placed on the top surface of the Steering
Position Sensor (as shown below in Figure 1) with the label facing up where it should be visible to the
operator.
Steering Position Sensor Warning label
Hydraulic Warning Label
This label should be placed on the steering assist manifold or on the Hydraulic Valve Mounting Bracket
as shown below in Figure 2. ‘Tampering with hydraulic valves may cause serious injuries or
death & will void warranty’.
NOTE: That the picture shown below is only an example on where the hydraulic warning label is to be
positioned on the steering assist manifold. Placement will vary depending on the valve used.
Hydraulic Warning label
