CHAPTER 9
98 Viper/Viper 4+ Installation & Operation Manual
GS-SATELLITE
Use the following settings and subscription information to manage GS correction services on the ROS device:
Satellite. The satellite identities is used to select the satellite for the region in which the ROS device will be
operating. Set this option to AUTO to allow the device to automatically select the satellite.
TABLE 2. Region Identities
NOTE: Visit the Raven web site for additional information and assistance with the satellite region identities.
www.ravenhelp.com
Accuracy Warning. The accuracy warning value sets the allowable horizontal accuracy for field operation. When
the receiver determines the position solution meets the set value, the solution will be considered converged
and the appropriate status will be display.
NOTE: Higher values will allow the receiver to converge faster, but will allow more horizontal position error.
Smaller values will provide more accurate position, but will take longer to converge and are more
likely to lose a converged status during field operations.
The following information is displayed in the Subscription Status area of the Differential Settings tab when
configured for GS-Satellite corrections:
Expires. A display of the current time remaining before the GS subscription expires. Contact a local Raven dealer
or access the Slingshot store at the web address below to extend subscription services.
https://ravenslingshot.com/store
ID Description ID Description
98W
North America and Western
South America
IOR
Eastern Europe and Africa, Asia,
and Western Australia
AOR
W
Eastern North America and
South America
143.5E Eastern Asia and Australia
AORE
Eastern South America,
Western Europe and Africa
POR
Eastern Asia and Australia and
Western North America
25E
Europe, Africa, and Western
Asia
