ray FACE - Performing Scanner Calibration

RAYFace 3. Installation
27
Proceed with Calibration
After placing the assembled Calibration Kit in front of the RAYFace, insert it into the front of the
base and align it in the correct position.
Make sure to insert the calibration base correctly until the printed side is not
visible.
Connect the calibration port on the back of the RAYFace to the port of the calibration kit with the
included UBS cable to prepare for calibration and then proceed with calibration.
