Rayco RG1645S - Dual Wheel Assembly; Coupler Assembly; Swing-Out Assembly

Parts Section
18
Rayco RG1645S Copyright © 2012 Rayco Mfg - All Rights Reserved
Printed in U.S.A.
32
4
1
ITEM QTY. PART # DESCRIPTION
1 1 28480 WHEEL-TIRE OUTER LH
2 1 19892 WRENCH, DUAL WHEEL
3 1 28486 WHEEL-TIRE OUTER RH
4 6 3549 COUPLER ASSEMBLY
DUAL WHEEL (28482)
41 32
ITEM QTY. PART # DESCRIPTION
1 1 3549W COUPLER WELDMENT
2 1 4900-08 WASHER 1/4” X .406 X 1
3 1 750061 NUT-WHIZ 3/8-16 GR5 HNFS
4 1 750060 PIN-ROLL 3/32 X 7/16”
COUPLER ASSEMBLY (3549)
41 32
