Parts Section
30
Rayco RG1645S Copyright © 2012 Rayco Mfg - All Rights Reserved
Printed in U.S.A.
3413
11
12
147 1512810651617
9
ENGINE ENCLOSURE ASSEMBLY (28319)
ITEM QTY. PART #
DESCRIPTION
1 3 722110 BOLT WHIZ 1/4-20 X 3/4
2 3 750768 NUT WHIZ 1/4”-20
3 10 750762 BOLT WHIZ 5/16-18 X 3/4
4 10 750764 NUT WHIZ 5/16”-18
5 4 726201 WASHER - FLAT 5/16
6 4 750050 NUT LOCK 5/16-18 NYLON
7 2 750124 SCREW-FH SLOT 1/4-20 X 1
8 2 724508 NUT LOCK 1/4-20 NYLOCK
9 1 23645 TOP COVER PLATE
10 1 23647 COVER DOOR LH
11 1 23646 COVER DOOR
12 1 28317 SIDE COVER LH
13 1 28315 SIDE COVER RH
14 1 23600 SOA BLOCK
15 1 28318 BRACKET,SOA STOP
16 4 722205 BOLT HEX 5/16-18 X 1 GR8
17 4 726101 WASHER FLAT 1/4 USS
