Parts Section
29
Copyright © 2012 Rayco Mfg - All Rights Reserved Rayco RG1645S Stump Cutter
Printed in U.S.A.
ITEM QTY. PART # DESCRIPTION
1 10 750061 NUT-WHIZ 3/8-16 GR5
2 10 750399 BOLT WHIZ 3/8-16 X 1
3 1 722503 BOLT HEX 1/2-13 x 1 1/4
4 1 4900-80 WASHER 3/8 X .531 X 2.0
5 1 726502 WASHER LOCK 1/2
6 6 726202 WASHER LOCK 5/16” PLATED
7 4 750071 BOLT - HEX M16 X 2.0 X 35
8 8 763434 WASHER FLAT 5/8” HARDEN
9 8 726702 WASHER LOCK 5/8
10 4 722304 BOLT-HEX 3/8-16 X 1 1/4
11 10 726302 WASHER-LOCK 3/8
12 2 722303 BOLT-HEX 3/8-16 X 1
13 4 726301 WASHER FLAT 3/8 USS
14 1 722849 BOLT METRIC 8-1.25 X 35
15 1 762608 BOLT METRIC 8 X 1.25 X 25
16 1 724920 NUT METRIC 8MM-1.25
17 2 750389 WASHER METRIC LOCK 8MM PL
18 2 722832 BOLT METRIC 8-1.25 X 30
19 14 764520 BOLT METRIC 10 X 1.25 X 25
20 14 726954 WASHER METRIC LOCK M10
21 4 762085 BOLT - HEX M16 X 2 X 45
22 4 760330 BOLT MSHCS 8 X 1.25 X 16
23 4 722302 BOLT HEX 3/8-16 X 3/4 GR8
24 6 762008 BOLT SHCS 5/16-18 x 1
25 1 620009 GEARBOX-90DEG 2.21 RATIO
26 1 764603 INDICATOR-SERVICE 50MB
27 1 20235 SIDE ENGINE MNT.WELD LH
28 1 20237 SIDE ENGINE MNT.WELD RH
29 1 20260 STUB SHAFT WELD SJRD
30 2 20265 PLATE, FLYWHL HSG SJRD
31 1 800119 CLUTCH/BRAKE-WARNER ELEC.
32 1 2583-08 3/8 KEYSTOCK X 3 1/4
33 1 20352 CLUTCH COVER MOUNT WELD
34 1 20408 SCREEN WELDMENT, RADIATOR
35 2 730024 CLAMP-HOSE #4
36 1 800979 COUPLER-48/60 HUB WITH SPIDER
37 1 801698 RADIATOR ASSEMBLY
38 1 28279 PIPE,EXHAUST WELDMENT 45SJRS
39 1 27097 CLUTCH COVER WELD 1645SJRS
40 1 28282 BRACKET,RAD LOWER MOUNTING
41 1 800877 PUMP-TANDEM 4.27/1.07 CC
42 1 800009 NUT-CAGE 1/4-20
43 4 722110 BOLT WHIZ 1/4-20 X 3/4
44 4 750768 NUT WHIZ 1/4”-20
45 1 724205 NUT HEX 1/4-28 UNF GR8
46 1 726102 WASHER-LOCK, 1/4”
47 1 800374 ENGINE-42HP KUBOTA
48 1 801361 KNOB 1/4-20
49 1 28458 HINGE SHIM
50 1 28508 PIPE, INTAKE
51 1 760934 ADAPTOR-AIRCLEANER
52 4 1200055 CLAMP-HOSE 1-9/16” X 2-1/2”
53 1 750069 BALL JOINT-10-32 X 1/4-28
54 1 800307 CLAMP-VINYL COVERED1-1/2”
55 1 22274 WIRE-ENGINE GROUND
56 2 750140 CLAMP-SPRING ACTION 1/2”
57 2 750764 NUT WHIZ 5/16”-18
58 2 750762 BOLT WHIZ 5/16-18 X 3/4
59 1 28544 ENCLOSURE, ENGINE WELDMENT
60 1 28543 DOOR, ENGINE COMP.
61 1 802275 SEAL, FLAP
62 1 763236 HINGE-TOOLBOX
63 1 750679 ELBOW-RUBBER 90D 2”
64 1 20420 HARNESS, CLUTC PIGTAIL
ENGINE ASSEMBLY (28292)
