Rayco RG1645S User Manual

Parts Section
42
Rayco RG1645S Copyright © 2012 Rayco Mfg - All Rights Reserved
Printed in U.S.A.
HYDRAULIC ADAPTER KIT (802194A-A)
Represented by circles on drawing
HYDRAULIC HOSE KIT (764767H-W)
Represented by squares on schematic
HYDRAULIC ADAPTER KIT (802194A-A)
REPRESENTED BY CIRCLES ON SCHEMATIC
ITEM QTY PART # DESCRIPTION
1 1 FF6602-04-04-04 TEE RUN -4MFFX -4MFFX
-4FFFX
2 4 FF6802-06-10 ELBOW 45 DEG-6MFFX-I0MOR
3 1 FF6502-08-08 ELBOW 45 DEG -8FFFX
-8MFFX
4 8 FF6802-04-06 ELBOW 45 DEG-4MFFX-6MOR
5 4 FF6400-04-10 CONNECTOR -4MFFX-I0MOR
6 2 FF6801-06-06 ELBOW 90 DEG-FIT -6MFFX
-6MOR
7 1 FF6801-08-08 ELBOW 90 DEG-8MFFX -8MOR
8 1 FF6600-08-08-08 TEE-8MFFX -8MFFX -8FFFX
9 2 FF6500-04-04 ELBOW 90 DEG-4MFFX
-4FFFX
10 1 2501-10-08 ELBOW 90 DEG-I0MJIC
-8MNPT
11 1 FF6802-08-08 ELBOW 45 DEG-8MFFX -8MOR
12 1 2404-06-04 CONNECTOR -6MJIC -4MNPT
13 6 FF6400-04-04 CONNECTOR -4MFFX -4MOR
14 2 6400-06-06 FIT-6MJIC -6MOR
15 1 FF2700-04-04LH BULKHEAD UNION
16 1 5406-C-6 CAP-6FP
17 1 FF6400-04-08 CONNECTOR -4MFFX -8MOR
18 1 9500-12MM WASHER 12MM
19 1 9605-06-12xl.25 CONNECTOR-6MJ-
12MMXl.25MMT
20 8 FF6400-04-06 CONNECTOR -4MFFX -6MOR
21 2 FF6802-04-04 ELBOW 45 DEG-4MFFX-4MOR
22 11 FF6801-04-06 ELBOW 90 DEG-4MFFX -6MOR
23 2 FF6804-04-04-04 TEE RUN -4MFF X -4MFFX
-4MOR
24 5 FF6801-04-04 ELBOW 90 DEG-4MFFX -4MOR
25 2 FF6400-08-08 CONNECTOR -8MFFX -8MOR
26 1 FF6600-04-04-04 TEE-4MFFX-4MFFX-4FFFX
27 2 FF6500-08-08 ELBOW 90 DEG-8MFF -8FFFX
28 1 FF6400-08-06 CONNECTOR -8MFFX -6MOR
HYDRAULIC HOSE KIT (802194H-A)
REPRESENTED BY SQUARED ON SCHEMATIC
ITEM QTY PART # D]f CRIPTION
1 1 HOSE 4RlT-6FFX-4FFX90-123”
2 1 HOSE 4RlT-6FFX-4FFX-125”
3 1 HOSE 1ORIT-1 OFTICX-8FFX-70”
4 1 HOSE 4RlT-4FFX-4FFX-18”
5 1 HOSE 4RlT-4FFX-4FFX90-60”
6 1 HOSE 4RlT-4FFX-4FFX90-53”
7 1 HOSE 4RI7-4FFX-4FFX-38”
8 1 HOSE 4RI7-4FFX-4FFX90-30”
9 1 HOSE 4RI7-4FFX-4FFX90-74”
10 1 HOSE 4RI7-4FFX-4FFX-88”
11 1 HOSE 4RI7-4FFX-4FFX-44”
12 1 HOSE 4RI7-4FFX-4FFX-34”
13 1 HOSE 4R17-4FFX-4FFX-74”
14 1 HOSE 4R17-4FFX-4FFX90-77”
15 1 HOSE 4RlT-6FFX-4FFX45-60”
16 1 HOSE 4R17-4FFX-4FFX90-69”
17 1 HOSE 4RlT-4FFX-4FFX-5l”
18 1 HOSE 4RlT-4FFX-4FFX45-39”
19 1 HOSE 4RlT-6FFX-4FFX-65”
20 1 HOSE 8RlT-8FFX-8FFX90-22”
21 1 HOSE 4RlT-4FFX-4FFX45-46”
22 1 HOSE 4RlT-4FFX-4FFX90-68”
23 1 HOSE 4RlT-6FFX-4FFX45-69”
24 1 HOSE 4RlT-6FFX-4FFX-66”
25 1 HOSE B16150-PLAIN-PLAIN-33”
(PROTECTION FOR BATTERY
CABLES)
26 1 HOSE 4RI7-4FSX-4FSX-66”
27 1 HOSE 4RlT-4FSX-4FSX-55”
28 1 HOSE H05705-PLAIN-6FJX90-9”
29 1 HOSE 6FL-6FIX-6FJX-9”
30 1 HOSE H05705-PLAIN-PLAIN-71 “
31 1 HOSE 3FL-PLAIN-90”
32 1 HOSE 4RI7-4FFX-4FFX45-13”
33 2 HOSE 4RI7-4FFX-4FFX45-16”
34 1 HOSE 4RI7-4FFX-4FFX45-20”
35 1 HOSE 143-06-6MP-6FJX-22”
36 1 HOSE 8RlT-8FFX-8FFX-68”
37 1 WRAP FWLD-16-30”
38 1 SLEEVE TQS-3-25” (3” VELCRO
SLEEVE)
39 1 HOSE 4RlT-4FFX-4FFX90-13”
