Parts Section
21
Copyright © 2012 Rayco Mfg - All Rights Reserved Rayco RG1645S Stump Cutter
Printed in U.S.A.
ITEM QTY. PART # DESCRIPTION
1 4 760261 NUT-LOCK 3/8-16 NYLON
2 4 750768 NUT WHIZ 1/4”-20
3 6 750765 BOLT WHIZ 1/4-20 X 1/2
4 7 750764 NUT WHIZ 5/16”-18
5 1 750325 RING-RETAIN EXT HVY 1”
6 2 736101 CLAMP-MUFFLER 2-1/2”
7 1 736023 HOURMETER
8 1 24644 HANDLE,ASSEMBLY SOA
9 1 23618 BUSHING SOA PIVOT
10 4 23297 GRIP, VALVE HANDLE
11 2 760408 SWITCH-SPST ON-OFF
12 1 735999 SWITCH-IGN 3/4 CYL 1011
13 3 750400 BOLT WHIZ 5/16-18 X 1/2
14 10 722110 BOLT WHIZ 1/4-20 X 3/4
15 4 764216 SCREW-BSH 1/4-20 X 3/4
16 19 724508 NUT LOCK 1/4-20 NYLOCK
17 4 726607 FENDER WASHER
18 4 722103 BOLT HEX 1/4-20 X 3/4 GR8
19 3 722207 BOLT HEX 5/16-18 X 2- 1/2
GR8
20 1 28271 ARM,WELDMENT SOA
45SJRS
21 1 28273 COVER,WELDMENT SOA
45SJRS
22 1 28274 BRACKET, WINDOW SOA
45SJRS
23 1 28276 WINDOW BRACKET
24 1 28277 CURTAIN-RUBBER
25 1 765271 SENSOR-PHOTOELECTRIC
26 1 6385Y THROTTLE, CW, MOUNT
LEVER
27 1 750315 SWIVEL KIT
28 1 738004 VALVE-3 SPOOL
29 1 750314 LEVER-CONTROL
(STRAIGHT)
30 1 20605 SHIELD-OPERATOR SOA
31 1 802203 CABLE-THROTTLE
32 1 801514 BOLT WHIZ 5/16-18 X 1-1/2
33 1 726907 WASHER FLAT 1-14GA
34 1 802228 VALVE-1 SPOOL MOTOR
35 3 722837 BOLT METRIC 8-1.25 X 16
36 3 750389 WASHER METRIC LOCK
8MM PL
37 1 730038 STRAP-TARP W/S-HOOK 10”
38 1 750050 NUT LOCK 5/16-18 NYLON
39 1 722118 BOLT WHIZ 1/4-20 X 1
40 1 726201 WASHER - FLAT 5/16
41 1 726101 WASHER FLAT 1/4 USS
42 5 802336 INDICATOR LIGHT, RED
43 1 29269 SWITCH, SEALED CW
1645SJRS
SWING-OUT ASSEMBLY (28278-D)
