Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of Global Version 2000 W CW laser
Raycus User Guide | Installation
3.4 Installation rule
1) Place the product in an appropriate position, immobilize it if necessary.
2) Check if the power supply has the correct voltage (laser model and
power voltage refers to product parameters in Table 5), and the earth line
is connected, make sure it is firm and reliable
3 ) Connect the power cable and control cable to the product when power
supply is OFF.
4) Connect the cooling system to the laser and output fiber cables according
to the water inlet and outlet signs.
5) Please check the laser output head and do the necessary cleaning before
installing it in the device. If you find that there is dust or foreign objects
that cannot be cleaned, please contact Raycus in time, and do not
continue installation and operation for the time being.
6) Prevent the delivery cable from treading, pinching or excessive bending
during installation.
7) Please handle the laser output cable carefully, and do not receive
vibration during the installation and disassembly.
8) Make sure the environment is clean, or the output head may be
contaminated. It is prohibited to use fan during installation, which will
cause dust in the air.
9 ) The minimum bending diameter of the transmission cable of the laser
shall not be less than 20cm in the non-working state (such as transport
and storage) . The minimum bending diameter should not be less than
30cm when the laser is work.
CAUTION: All the cables can only be connected
when power supply is off. Hot plug may damage the device.
