Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of Global Version 2000 W CW laser
Raycus User Guide | Using the Product
4.5 Installation Instruction
1) Take out the laser carefully, move it to the installation position, fix the
laser with screws through the installation holes on the front panel of the
machine.
2) Remove the protection cap of the output head, use strong light to check
if there is dust on the lens of the output end. If so, please clean it before
use, and then cover the protection cap of the output head.
3) Install the output optical cable on the processing equipment according to
the actual situation (also install the output head cooling water pipe), pay
attention to arrange the output optical cable, and protect the output head.
After installing and arranging the output optical cable, remove the
protective cap, and check whether the output lens is clean again, and then
install the output head;
4) Remove the rubber pipe plug and safety clip at the quick connect joint of
the inlet and outlet, connect the laser cooling water pipe, and then install
the safety clip back;
5) Connect the control line and power supply according to the control
mode.
4.6 Start operation sequence
Make sure the air switch is off. All electrical connections must be completed
before the laser is powered on.
1 ) Turn on the chiller and check the water pipe for leaks. If there is no
leakage, turn off the chiller and wait for the laser to turn on;
2) Ensure that PIN 1 and PIN 4, PIN 2 and PIN 3 Interlock on DB25 PINS
have been short-circuited and closed; Ensure that the remote power-on
switch of PIN 8 and PIN 9 have been short-circuited and closed; Ensure
that PIN 10 and PIN 11 emergency stop switches have been
short-circuited and closed;
