Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of Global Version 2000 W CW laser
Raycus User Guide | Using the Product
should be set to a disabled state. When the external modulation mode is turned on,
the frequency, pulse width and duty cycle are controlled by the external
modulation signal, and the function of the software to set the frequency, pulse
width and duty cycle should be set to the disabled state.
Control the light: control to turn on or off the laser emission or laser enable.
Only when the laser has a ready signal, can it be controlled normally, otherwise the
buttons for turning on and off the laser are set to the disabled state. When the
external control light enable is turned off, and the external modulation mode or
internal modulation mode is turned on, the "laser enable" is displayed, otherwise,
the "laser emission" is displayed.
Status display: Including emergency stop, laser enable, Interlock logic normal,
Interlock1 closed, Interlock2 closed, power ramp up and down, program mode,
program execution, program execution completed, program execution abnormal
and other most commonly used laser states, and machine Internal ambient
temperature, internal ambient humidity, dew point, external 0- 10V, light output
frequency, light output duty cycle, light pulse width, laser water flow, output
optical cable water flow and other data. These status and data refresh time intervals
should not exceed 300ms.
Laser usage time display: including today's turn-on time, today's
light-emitting time, cumulative turn-on time, and cumulative light-emitting time.
4.7.2 The alarm interface
All the alarm information of the current laser is displayed on the alarm
interface, and the alarm information is updated in real time.
