Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide
RFL-C2000S-HP /RFL-C3000S-HP /RFL-C4000S-HP/RFL-C6000S-HP
28
Other
Commanderror
Send：“BGM\r”
Return
：
“BCMD\r”
STA
Read device status
– Read the product status. The return
value is 32Bit digital information. The
meanings of each bit are as follows
(undefined or "reserved" bits can be
ignored):
Bit 0
0-Normal operation
Send：“STA”
Return
：
“STA
：
4100”
The return value 4100 (decimal) can
be converted to 0x1004
(hexadecimal), and then converted
to binary. It can be seen that Bits2
and 12 have been set. That
means"Laser Enable" is turned on
and "Modulation" mode is enabled
1-Authorization time
Bit 1
0-Normal
1-Overheat
Bit 2
0-Laser not enabled
1-Laser enabled
Bit 3
0-Back Reflection OK
1-High Back Reflection
Level
Bit 4
0-External AD mode=off
1-External AD mode=ON
Bit 5
Reserved
Reserved
Bit 6
0-Normal
1-Slave communication
abnormal
Bit 7
Reserved
Reserved
Bit 8
0-Aiming Beam OFF
1-Aiming Beam ON
Bit 9
0-Laser not ready
1-Laser ready
Bit 10
0-QCW mode=off
1-QCW mode=on
Bit 11
0-main power supply=OFF
1-main power supply=ON
Bit 12
0-Modulation Disabled
1-Modulation Enabled
Bit 13
Reserved
Reserved
Bit 14
Reserved
Reserved
Bit 15
0-Laser does not emit beam
