Raycus RFL-C3000S-CE User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL- RFL-C3000S-CE
25
3
RX+
RECEIVE+
4
N/C
NONE
5
N/C
NONE
6
RX-
RECEIVE-
7
N/C
NONE
8
N/C
NONE
For better communication stability, recommend to use this interface first.
Table 9The default IP address of the laser
The default IP address of the laser
IP address
192.168.0.10
Subnet mask
255.255.255.0
Steps of Ethernet connection:
a) Open “Local Connection” on your computer, and then click “property”;
b) Select "Internet Protocol Version 4 (TCP/IP 4)；
c) Click the “Property”;
d) Check “Use the following IP address:” to manually assign an IP address;
e) Manually assign an IP address is 192.168.0. x（x cannot be 10, because 192.168.0.10 has
been assigned to the laser ） , and assign a subnet mask address. The default is
255.255.255.0;
f) Click the "OK" button to confirm the settings and exit. The IP address is different from
the default gateway, see Figure 9.
