Raymarine AXIOM 2 PRO - Downvision Transducers; CPT-S Conical Beam Transducers; CHIRP Transducers

Down
Vision™transducers
DownVision™transducersrequireanadaptercable(partnumber:A80490),
andconnecttothe25-pinRV/RVMtransducerconnector.
T ransommounttransducers
P artnumber
Transducerdescription
A 80507CPT-90DVSDownVision™plastictransducer
A 80351CPT-100DVSDownVision™plastictransducer
Thru-hullmounttransducers
P artnumber
Transducerdescription
A 80277CPT-110plastictransducer
A 80350CPT-120bronzetransducer
CPT-Sconicalbeamtransducers
•CPT-Stransducersrequireanadaptercable(partnumber:A 80490),and
connecttothe25-pinRV/RVMtransducerconnector.
•CPT-StransducersdoNOTofferDownVision™capabilities.
T
ransommounttransducers
P
artnumber
Transducerdescription
E70342CPT-Splastictransducer
Thru-hullmounttransducers
P
artnumber
Transducerdescription
E70339CPT-S0°Angledelementplastictransducer
A80448CPT-S12°Angledelementplastictransducer
A80447CPT-S20°Angledelementplastictransducer
A80446CPT-S0°Angledelementbronzetransducer
E70340CPT-S12°Angledelementbronzetransducer
E70341CPT-S20°Angledelementbronzetransducer
In-hullmounttransducers
Partnumber
Transducerdescription
A80691CPT-Splastictransducer
CHIRPtransducers
•CHIRPtransducersconnectdirectlytothe11-pin1kWtransducerconnector.
•CHIRPsplit-pairtransducersrequireaY-cable(partnumber:A102146).
•B75&B175transducersrequireanoperationcable(partnumber:A80328).
Compatibletransducers
23
