Raymarine AXIOM 2 PRO - Accessory Connection

16.
1Accessoryconnection
Axiom®2ProdisplaysincludeabuiltindualslotMicroSDcardreader.
TheAccessoryconnectorcanbeusedtoexpandstoragecapabilitiesby
connectinganexternalmemorycardreaderorexternalstoragedeviceto
thedisplay.
1.A CCESSORYconnector.
2.Accessorydevice:
•RCR-SDUSB(partnumber:A80440)—Includes1xSDcardslot(or
MicroSDcardwhenusinganSDcardadaptor)and1xUSB(TypeA
connector)(e.g.forconnectionofanexternalUSBharddriveorpen/
flashdrive).TheUSBslotontheRCR-SDUSBcanalsosupply0.5Aof
currenttochargemobiledevices.
•RCR-1(partnumberA80585)—Includes1xMicroSDcardslot.
•BulkheadMountMicroUSBSocket(partnumber:A80630)—
Includes1xMicroUSB(TypeMicroAconnector)(e.g.forconnectionof
anexternalUSBharddriveorpen/flashdrive;anadditionaladaptor
mayberequiredfortheconnectionofsomeUSBdevices).
•Tosavescreenshots(.pngfiles),[ExternalSD]or[ExternalUSB]mustbe
selectedasthe[ScreenshotFile]locationonthe[Thisdisplay]tabinthe
maindisplaysettingsmenu(accessiblefromHomescreen).
•Tosavevideo(.movfiles),[ExternalSD]or[ExternalUSB]mustbeselected
asthe[SaveFiles]locationonthe[Photo&Videorecording]tabinthe
Videoappsettingsmenu.
Forinstallationdetailsforthesedevices,pleaserefertotheinstructions
providedwithyouraccessory.
Warning:USBdevicepower
DoNOTconnectanydevicetotheproduct’sUSBconnection
thatrequiresanexternalpowersource.
USBconnections73
