1RealVisiontransducerconnection
RealVision™3DandRealVision™Max3Dtransducerscanbeconnected
directlytothedisplay’s25-pinRV/RVMTransducerconnectionusingthe
cable(s)suppliedwiththetransducers.
Example—RealVisionMax3Dsplitpairtransducerconnections
1.Display’ sRV/RVMTransducer25-pinconnector.
2.Optionalrightangledadaptor(partnumber:A80515)suppliedseparately
(usedtoreducethespacerequiredbehinddisplay).
3.‘Y’cable(suppliedwithsplitpairtransducerpacks)
4.8m(26.2ft)extensioncable(suppliedwithsplitpairtransducerpacks)
5.Optionalextensioncablescanbefittedbetweenthetransducerand‘Y’
cableifrequired,orbetweensuppliedextensioncableanddisplay.
6.Transducer,e.g.:RVM-412Port.
7.Transducer,e.g.:RVM-412Starboard.
ForalistofcompatibleRealVision™Max3Dtransducersreferto:
p.21—RealVision™Max3Dtransducers
ForalistofcompatibleRealVision™3Dtransducersreferto:
p.21—RealVision™3Dtransducers
W
arning:Maximumtransducercablelength
ThemaximumlengthofcablebetweenaR
ealVision™Max
3DtransducerandaMFD/sonarmodule(includingthe
transducer’scaptivecable)mustNOTexceed18m(59ft).
Cablelengthsgreaterthanthismaycausedamagetothe
RealVision™Max3DtransducerandMFD/sonarmodule.
W
arning:Transducercables
Donotremovethetransducercablewhilsttheproductis
poweredon,doingsocancausespark
s.Ifthetransducer
cableisaccidentlyremovedwhilsttheproductispoweredon,
switchtheproduct'spoweroff,replacethecableandthen
switchthepowerbackon.
Caution:Donotcuttransducercables
•Cuttingthetransducercableseverelyreducessonar
performance.Ifthecableiscut,itmustbereplaced,it
cannotberepaired.
•Cuttingthetransducercablewillvoidthewarrantyand
invalidatetheEuropeanCEmark.
RealVisiontransducerextensioncables
Y ourtransducerissuppliedwithafittedcable,forsomeinstallations
(includingallsplit-pairtransducerinstallations)itmaybenecessarytoextend
thelengthofthetransducercable.
Note:
•Forbestperformance,cablerunsshouldbekepttoaminimum.
•OnlyuseRaymarine®transducerextensioncables.
Raymarine®offershefollowingoptionalextensioncablesareavailable:
•RealVision™transducerextensioncable3m(9.8ft)(partnumberA80475)
•RealVision™transducerextensioncable5m(16.4ft)(partnumberA80476)
•RealVision™transducerextensioncable8m(26.2ft)(partnumberA80477)
T ransducerconnections-Axiom2ProRVM63
