More information....
See the 'Using the Radar' chapter of the Reference Manual.
D6732_2
How do I set up a circular guard zone?
Turn to set
inner boundary.
NOTE: You can also set up a sector guard zone.
OK
Press
TARGET
TRACKING...
Press
MONITOR
IN ZONES...
Press Toggle to ON
ZONE 1
OFF ON
Press
SET UP
ZONE 1
Press
ZONE SHAPE
SET INNER
Press
Turn to set
outer boundary.
Toggle to
required type
SECTOR CIRCLE
1. Select guard zone function:
2. Select guard zone option:
Press
What does a guard zone displayed?
Will only operate when a whole zone is
displayed on the screen, or is displayed by
offsetting the centre.
Is inactive for 10 seconds after it is placed
or re-sized, to avoid inappropriate alarms.
Sector Zone
SHM
Circular Zone
SHM
IMPORTANT
A guard zone:
How can the radar help me avoid a collision?
You can set up your E-Series Display to sound an alarm when anything comes within a pre-set range of
the boat. These guard zones allow you to take any necessary action to avoid a collision.
Guard zones
A sector or circular zone fixed with respect to the Ships Heading Marker (SHM). If the SHM moves, or the
centre is offset, or the range scale changes, the zone moves accordingly.
What is around me?
Avoiding a collision
Card No. 10
VRM/EBL
TARGET
TRACKING
GAIN TARGETS PRESENTATION
