Raymarine G-Series User Manual

Fuse/Breakers
•12Vsystem:8Athermalbreaker
or12Aratedfuse.
•24Vsystem:4Athermalbreaker
or6Aratedfuse.
CurrentG120
•4A@12Vdc
•2A@24Vdc
G150
•4A@12Vdc
•2A@24Vdc
G170
•7.6A@12Vdc
•3.5A@24Vdc
G190
•7.7A@12Vdc
•3.6A@24Vdc
Mechanical
Weight
•G120:4.6kg(10lb)
•G150:5.8kg(12lb)
•G170:6.4kg(14lb)
•G190:7.3kg(16lb)
D118 93 -1
G120
G150
330 mm
(13.00”)
A
380 mm
(14.97”)
284 mm
(11.18”)
B
315 mm
(12.39”)
307 mm
(12.08”)
C
357 mm
(14.07”)
257 mm
(10.10”)
D
292 mm
(11.5”)
118 mm
(4.64”)
118 mm
(4.64”)
E
G170
415 mm
(16.34”)
G190
454 mm
(17.87”)
358 mm
(14.10”)
394 mm
(15.51”)
335 mm
(13.19”)
100 mm
(3.94”)
389 mm
(15.31”)
432 mm
(17.00”)
366 mm
(14.41”)
100 mm
(3.94”)
A
E
C
D
B
Environmental
Environmental
•Operatingtemperature:-10ºCto
+50ºC(14ºFto122ºF)
•Relativehumidity:max95%
•WaterprooftoIPX6(ratingapplies
tofrontofmonitor).
154G-Seriesinstallationinstructions
