Raymarine G-Series - Component Mounting Guidelines

4.3G-Seriesmonitors
ForinstallationinstructionsforG-Seriesmonitorsrefertothe
documentationthataccompaniestheproducts.
MonitorDocumentnumberDocumentname
G-SeriesG120,G150,
G170,G190
81277
RaymarineSunlight
ViewableMarine
Displays—User’s
Guide
G-SeriesGlassBridge
GB150,GB170
81324
GlassBridgeMonitors
—User’sGuide
Partssupplied
D118 01 -1
6
1
2
3
4
5
1.Suncover.
2.Monitor.
3.Mountingbrackets(quantity:2).
4.1.5m(4.9ft)Powercable.
5.5m(16.4ft)DVI-Dcable.
6.Installationinstructions.
