Note:Themaximumlengthfortheradarpoweranddatadigital
cable(includinganyextensions)is25m(82ft).
SeaTalk
hs
networkcables
CablePartnumber
1.5m(4.9ft)SeaTalk
hs
networkcable
E55049
5m(16.4ft)SeaTalk
hs
networkcable
E55050
10m(32.8ft)SeaTalk
hs
networkcable
E55051
20m(65.6ft)SeaTalk
hs
networkcable
E55052
SeaTalk
hs
patchcables
CablePartnumber
1.5m(4.9ft)SeaTalk
hs
patchcable
E06054
5m(16.4ft)SeaTalk
hs
patchcable
E06055
10m(32.8ft)SeaTalk
hs
patchcable
E06056
15m(49.2ft)SeaTalk
hs
patchcable
A62136
20m(65.6ft)SeaTalk
hs
patchcable
E06057
FullywaterproofSeaTalk
hs
networkcables
Connectdirectlyfromdisplaytodisplay.
CablePartnumberNotes
1.5m(4.9ft)Dualend
SeaTalk
hs
networkcable.
A62245
Cablehaswaterproof
connectorsatbothends.
15m(49.2ft)Dualend
SeaTalk
hs
networkcable
A62246
Cablehaswaterproof
connectorsatbothends.
SeaTalkhshardware
CablePartnumberNotes
SeaTalk
hs
switch
E55058
8wayhubfornetwork
connectionofmultiple
SeaTalk
hs
devices.
SeaTalk
hs
coupler
E55060
Couplerforconnection
ofasingleSeaTalk
hs
device.
162G-Seriesinstallationinstructions
