4.3Powerconnection
Thepowersupplyshouldbeconnectedasshownbelow:
1.Basestation
2.Powersupplypositive(+)Redwire
3.Powersupplynegative(-)Blackwire
4.Suitablewaterproofconnection(Basestationissuppliedwithbulletcrimpsonpowersupply
wires.)
5.12Vdcpowersource
Warning:12Voltdconly
Thisproductmustonlybeconnectedtoa12voltdcpowersource.
Warning:Positivegroundsystems
Donotconnectthisunittoasystemwhichhaspositivegrounding.
In-linefuseandthermalbreakerratings
Thefollowingin-linefuseandthermalbreakerratingsapplytoyourproduct:
In-linefuseratingThermalbreakerrating
10A
7A(ifonlyconnectingonedevice)
Note:
•Thesuitablefuseratingforthethermalbreakerisdependentonthenumberofdevicesyouare
connecting.IfindoubtconsultanauthorizedRaymarine
®
dealer.
•Y ourproduct’spowercablemayhaveafittedin-linefuse.Ifnot,addanin-linefusetothe
positivewireofyourproduct’spowerconnection.
Grounding
Thisproductisgroundedthroughthe0Vdcnegativewireonthepowercableanddoesnotrequire
adrain(shield)tobeconnectedtothebasestation’sgroundterminal.
