68 SmartPilot X-5R Drive Installation and Setup Guide
outputs, 61
O
Off course warning angle, 58
P
Parts supplied, 4
Pilot Controller
connecting, 23
SeaTalk power NOT supplied by
Course Computer, 24
SeaTalk power supplied by Course
Computer, 23
fitting, 23
Power cable requirement, 8
Power connection, 20
Power supply protection, 20
Product disposal, vi
R
Resetting the system, 59
Response level, 53, 57
Rudder damping, 57
Rudder gain, 56
setup, 45
Rudder indicator alignment, 56
setup, 36
Rudder limits, 56
setup, 36
Rudder reference option, 26
S
Safety
electrical, v
general, v
navigation, v
SeaTalkng connections, 27
Seatrial Calibration, 37
conditions, 37
heading alignment, 39
Seatrial calibration lock, 54
Setup
Accessing calibration modes, 50
AutoTrim, 46, 57
counter rudder, 46, 57
cruise speed, 59
data pages, 51
drive type, 36, 56
heading selection, 51
joystick, 58
latitude, 59
off course warning angle, 58
response level, 53, 57
rudder damping, 57
rudder gain, 45, 56
rudder indicator alignment, 36, 56
rudder limits, 36, 56
seatrial calibration lock, 54
turn rate limit, 58
vessel type, 35, 55
ST6002 Pilot Controller
connecting, 23
SeaTalk power NOT supplied by
Course Computer, 24
SeaTalk power supplied by Course
Computer, 23
fitting, 23
Switching on, 32
System defaults, 60
System grounding, 25
System overviews, 2
System reset, 59
T
Tools required, 5
Torque restraint, 13
Turn rate limit, 58
U
User calibration, 53
response level, 53
V
Vessel type, 55
setup, 35
W
Wheel shaft size, 12
