Raypak 5350 - Plumbing Diagrams

15
20. PLUMBING DIAGRAMS
WATER IN
(FROM POOL OR
SPA)
FILTER
CHECK VALVE
CHEMICAL INTRODUCTION
NO EXTERNAL BYPASS IS REQUIRED
WATER OUT (TO POOL OR SPA)
F10123
INLET AND OUTLET ARE 2" UNIONS
PLUMB THE UNIT AFTER THE FILTER, BEFORE ANY CHLORINATORS.
Figure 8. For Systems with Flow Less than 80 GPM (303 lpm)
