User Manual
15
NOTE: To adjust the IP ADDRESS，SUBNET MASK and GATEWAY value, only when the
[STATIC] mode is being selected.
GATEWAY: Set this number to the gateway
set by your modem/router.
DNS ADDRESS: This code should be
provided by your local ISP.
HTTP PORT: This port number is used to
communicate with PC Client. The default value is
80(Can be changed from 1024 to 49151)
USER SETUP: When accessing the DVR
from a remote location you will be prompted for a
login and password. The default is “admin” for
full administrator rights. Set “User ID” and
password to setup a user with limited rights to
prevent tampering.
USER SETUP
ADMIN ID [admin]
ADMIN PASSWORD
USER ID
USER PASSWORD
( )MOVE (SEL)SELECT (MENU)EXIT
NETWORK SETUP
MAC ADDRESS
IP ALLOCATION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
NETWORK SETUP
MAC ADDRESS
IP ALLOCATION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
NETWORK SETUP
MAC ADDRESS
IP ALLOCATION
IP ADDRESS
SUBNET MASK
GATEWAY
DNS1 ADDRESS
DNS2 ADDRESS
HTTP PORT
USER SETUP
DDNS SETUP
(HTTP PORT) 80, 1024-49151
( )MOVE (SEL)SELECT (MENU)EXIT
<00:11:22:33:44:55>
[STATIC]
[192.168.1.100]
[255.255.255.0]
[192.168.1.1]
[0.0.0.0]
[0.0.0.0]
[ 80]
