User Manual
24
that you want remotely access and then press Login to enter the main page.
Chapter 9: Specification
4 / 9-Channel DVR
Items Descriptions
Video Standard NTSC/PAL
Video Input/Output 4 Channels/2 Channels，9 Channels/1 Channel
Audio Input/Output 2 Channels/2 Channels，1 Channel/1 Channel
Resolution
NTSC:720X480@30fps(Each Ch)
PAL:720X576@25fps(Each Ch)
Monitoring
Features Full-D1，1-CH/4-CH/9-CH Display
Resolution
NTSC:720X240@60fps(4/9Ch.Total)
PAL:720X288@50fps(4/9Ch.Total)
Features Variable Frame Rate/Variable QL per Channel
Recording
Quality 4-Level(Highest, High, Normal, low)
Audio ADPCM2 CODEC
Video MPEG-4
Motion Detection Settable Window/Level
Microprocessor 32-bit RISC Processor
Network Interface TCP/IP(RJ45)
Network Monitor IE(Internet Explorer) PC Viewer Software
PTZ Interface RS-485
USB Interface USB 2.0
VGA Output Optional
Remote control IR remote control
