DASHBOARD DESCRIPTION (FIG.1)
1. Starting switch
Controls activation of all the electric system components.
Pos. 0 = electric system off, Pos.1 = electric system on
2. Multi-function display
On the model “MEGA I”, when switching on the machine, the display
shows a sequence of messages: model of the machine (RCM Mega I),
software version, working hours.
On the model ( MEGA I “S” special), when the electric system is activa-
ted the display shows the washing programme and the pre-set calibra-
tions as described below:
1. (RCM 01) with standard programme, or:
- (RCM 02 ) with programme for pump kit and detergent (optional).
- (RCM 03) with programme for pump kit without detergent (optional).
2. (Pb 24) calibration programme for lead-acid batteries (standard con-
fi guration), or: (GE 24) calibration programme for gel batteries (op-
tional confi guration) with 24V.
3. (000, 001,..etc.) indicates calibration settings and washer-dryer fun-
ctions update.
4. (0-100) the value shown indicates the charging status of batteries.
In all the versions (MEGA I and MEGA I “S” special), the working hours can
be shown by pushing the button 6.
Additionally, the display shows the machine faults. For descriptions see
“DIAGNOSTICS - DISPLAY page 66”.
!
Caution!
For BATTERY Confi guration see chapter “Optional | Machine Con-
fi guration WITH LEAD-ACID AND/OR GEL BATTERIES”.
!
Caution!
DO NOT modify the described programs or settings. For informa-
tions contact the RCM service center.
3. Drive speed adjusting potentiometer
Used to set the type of speed to be used during travel or work.
- Turn to the “tortoise” symbol to set the machine at a low speed
for thorough cleaning.
- Turn to the “hare” symbol to set the machine at a high speed
for travel between jobs.
- Turn to between the “tortoise and hare” symbols to set the
machine at a speed (and cleaning level) between the two ex-
tremes.
4. Drive control levers
The levers control the travel of the machine.
A= Forwards, R= Reverse
5. Emergency stop push-button
Cuts out the contacts for all the controls simultaneously.
If an emergency occurs, press this button. To restore operation, pull
up the button.
6. Commutation push-button battery status || hourmeter
Push the button to show on the display 2 the working hours or the
battery status charge.
7. Vacuum system on || off push-button
Switches on || off the vacuum motor.
The button has a led. When switching on the vacuum, the led blinks.
In normal working conditions the led is on. In case of over-absortion or
any other faults for the vacuum motor, the led blinks.
!
Caution!
The switching off the vacuum system is retarded by two seconds
to permit the completely emptying of the vacuum hose.
8. Brush push-button
On all the version, this button switches on/off the brushes rotation. In the ver-
sion ( MEGA I “S” special) it also lead the lifting/lowering and pressure on the
fl oor of the brush basement.
On the version ( MEGA I ), the lifting/lowering of the brush basement is actua-
ted through the pedal 11 (fi g. 3).
The button has a led. When switching on the brush button, the led blinks. In
normal working conditions the led is on. In case of over-absortion or any other
faults for the vacuum motor, the led blinks.
On the MEGA I "STANDARD" version (NOT SPECIAL "S") the adjustable pres-
sure of the brushes on the fl oor has 3 different positions (See Fig.3 - Pos.12):
a) base on;
b) base down;
c) base down with over pressure acted by the manual lifting arm in
upper position.
9. 2nd “brush pressure” push-button
Controls the max. “brush pressure” on the fl oor.
!
Caution!
If necessary, use this function for a stronger cleaning
.
!
Caution!
This function can be activated just when brush basement is lowe-
red and when machine is moving forward.
10. Brush water (fl ow) indicator (optional)
Shows the brush water fl ow setted by the push-buttons 12.
11. Detergent percentage setting push-button (optional)
Used to set up the program of dilution of the detergent on the brushes.
The choice of program depends of the dirt on the fl oor.
!
Caution!
This function is activated by the program (RCM 02) only.
This function controls three programs displayed in this way
- det.0 (pump switched off)
- det.1 (1% detergent diluted)
- det.2 (2% detergent diluted)
- det.3 (4% detergent diluted)
Push the button once to show on the display the current percentage
of detergent.
To set or modify the percentage of chemical from 1% to 4%, push the
button until the desidered percentage is showed on the display.
12. Water (fl ow) regulating push-buttons (optional)
Push on + or - to regulate the brush water fl ow. The regulating is shown
by the indicator 10.
!
Caution!
This function is activated by the programs (RCM 02 - RCM 03) only.
13. Water recycling push-button (optional)
14. Spray and suction device kit push-button (optional)
Controls the spray and suction device kit.
15. Diagnostic LED for drive chopper
The LED with a sequence of fl ashes indicates the anomalies on the drive
chopper.
For the fl ashes and anomalies description , see “DIAGNOSTICS - LED pag.64”.
