SAM 400 SPEED-AREA-DISTANCE METER
18
Connections for Cable S/CB/327-1-063
CONNECTOR – A
TERMINAL KEY COLOUR FUNCTION
1 0V BLACK POWER SUPPLY 0V
2 0V BLACK SENSOR 0V
3 0V BLACK SENSOR 0V
4 +V RED POWER SUPPLY +V
5 O/P 1 TURQUOISE HIGH SPEED OUTPUT
6 O/P 2 ORANGE MAX. SPEED OUTPUT
CONNECTOR – B
TERMINAL KEY COLOUR FUNCTION
1 I/P 1 GREEN SECURITY LINK +V (CONNECT TO GROUND)
2 I/P 2 YELLOW RPM +V
3 I/P 3 VIOLET WCI 1/2 WIDTH (BLUE) / ACI SIGNAL
4 I/P 4 BROWN WCI 1/4 WIDTH (BROWN)
5 I/P 5 BLUE AREA CUTOUT SWITCH
6 I/P 6 WHITE FORWARD SPEED +V
