SAM 400 SPEED-AREA-DISTANCE METER
8
Work Rate - Channel 4
This is the instantaneous work rate displayed in either hectares per hour or
acres per hour, depending on the units set in the Cal mode.
If a WCI switch or an ACI is installed, the work rate is automatically
recalculated based on the implement part width in operation.
Engine Hours - Channel 5
The instrument displays either the total engine hours, or the total hours that
the instrument is powered on, depending on the setting in the CAL mode.
Reset Engine / Ignition Hours
The "Engine Hours" channel can be reset in the same way as the "Partial
Area" and "Total Area" channels, however, the security link wire must be
connected from the terminal labeled “Security Link" on the AMP connector,
to 0V.
Select the channel then press and hold the button.
The display will flash for 5 seconds before the total is reset to zero.
RPM - Channel 6
Channel 6 typically displays the spinner speed, PTO speed or Engine speed,
but it can be for any other rotating shaft depending on your particular
application.
