General technical data
3
BAL_SYS20_RED_EN_2V2_REC_102-020110693 12/ 27
General technical data
NOTICE
Load capacity for lintel installations
The standard guidelines for load capacities on lintel installations can be found in
the corresponding chapter
NOTICE
3 carriages required for door weight per wing > 90 kg
4 carriages required for door weight per wing > 125 kg
Noise emission: < 45 dB
Protection class: IP20
Door opening speed
Door opening speed
(for max. 75% of authorized door
weight)
D-STA
D-TSA
0.7 m
1 sec.
E-STA
E-TSA
0.7m
1.5 sec.
Power supply data
Product line 20 Product line 21 22
Standard DUO / RED Standard RED Standard
Mains voltage 100-240 VAC 100-240 VAC 230 VAC 100-240 VAC 230 VAC
Rated power 90 W 90 W 85 W 90 W 120 W
Fuse protection 4 AT 4 AT 3,15 AT 4 AT 3,15 AT
Standby power
consumption*
approx. 25 W for all
* including sensors, control unit and locking device
3
3.1
3.2
