8540573 • 16/09/2016 • Rev.20 39
MI - MILR SERIES
Number of beams of light curtains for
detection of body in access control
2 – 3 – 4
Operating range Low / High
m
8 ÷ 30 / 18 ÷ 60
Muting system
Two-way with 2 or 4 sensors with max. concurrent actuation time 4 sec
Two-way sequential with 4 sensors
Muting Sensors
external with relay or PNP output
MI and MILR Multibeam SERIES
2B
3B
4B
Number of beams
2
3
4
Distance between beams mm
500
400
300
Response time ms
7
7
7
Overall barrier ht. mm
776
1076
1176
PFHd *
7,53E-09
7,70E-09
7,87E-09
DCavg
#
97,94%
97,99%
98,03%
MTTFd
#
years
100
CCF
#
80%
MILR SERIES Resolution 40 mm
604
904
1204
Number of beams
30
45
60
Response time ms
17
23
28,5
Overall barrier ht. mm
776
1076
1376
PFHd *
1,02E-08
1,17E-08
1,32E-08
DCavg
#
98,37%
98,49%
98,57%
MTTFd
#
years
100
CCF
#
80%
J – JLR SERIES
Heights of guarded areas
mm
310 ÷ 1810 for light curtains with a resolution of 40 mm
Resolution of light curtains for
detecting upper or lower limbs
mm
40
Number of beams of light curtains
for detection of body in access control
2 – 3 – 4
Operating range
Low / High (J models)
m
0 ÷ 6 / 1 ÷ 16
Operating range
Low / High (JLR models)
m
8 ÷ 30 / 18 ÷ 60
J – JLR Multibeam SERIES
2B
3B
4B
Number of beams
2
3
4
Distance between beams mm
500
400
300
Response time ms
7
7
7
Overall barrier ht. mm
736
1036
1136
PFHd *
7,53E-09
7,70E-09
7,87E-09
DCavg
#
97,94%
97,99%
98,03%
MTTFd
#
years
100
CCF
#
80%
* IEC 61508
#
ISO 13849-1
