Reflex GX616 - Details of Main Components

5.6.Details of main components：
LREFLEX-FASTFORM-GX616 ist of main components
NO NAME MODEL QYT NOTE
1
HMI
GL104E
1
2
CPU 1214C 6ES7 214-1AG40-0XB0
1
3
SM 1223
6ES7 223-1BL32-0XB0
1
4
SM 1222 6ES7 222-1BF32-0XB0
1
5
SM 1231
6ES7 231-4HD32-0XB0 1
6
switch EDS-205A
1
7 server Driver IS650PT112IUX-C 1
8 server Driver IS650PT045IUX 1
9 server Driver IS620PT3R5I-C 1
10 Servo connector S6-C3 2
11 Servo connector S6-C6 1
12 Servo connector S6-C2 1
13 Encoder cable S6-L-P01-5.0 3
14 Braking resistor 24
Ω
2000W 1
15 Braking resistor 2000W 18Ω 1
16 AC contactor CJX1-140/220V 1
17 AC contactor CJX2-1801/220V 4
18 thermal relay NR2-25 12-18A 3
19 transformer NDK-500VA-380V、420V/220V 1
20 Switching power supply ELG-150-24A 1
21 Switching power supply MOR-40-12 1
22 Relay MY2N-GS DC24 16
23 Aviation plug socket ∮48 .26 1
24 Terminal block UK-50 3
