Technical data
14
— English Vacuum spray degassing — 06.07.2016 - Rev. B
5
Technical data
Note!
The following values apply for all systems:
–
Permissible flow temperature:
–
Permissible operating temperature makeup
degassing:
–
Permissible ambient temperature:
–
Permissible operating gauge pressure:
–
Maximum inlet pressure for makeup:
–
Makeup capacity:
–
Separation level, dissolved gases:
–
Separation level, free gases:
–
Degree of protection:
120 °C
0 °C – 30 °C
0 °C – 45 °C
8 bar
6 bar
0.05 m³/h
≤ 90 %
100 %
IP 54
5.1
Electrical system
Type
Power output
(kW)
Power supply
(V / Hz)
Fusing
(A)
Number of RS-
485 interfaces
I/O module
Electrical voltage
control unit
(V, A)
Noise level
(dB)
30 0.47 230 / 50 10 1 No 230, 4 55
30 GL 0.47 230 / 50 10 1 No 230, 4 55
5.2
Dimensions and connections
Type
Weight
(kg)
Height
(mm)
Width
(mm)
Depth
(mm)
Degassing
device
connection
Degassing
system
connection
Make-up
connection
30 13.5 660 545 290 IG ½ " IG ½ " IG ½ "
30 GL 13.5 660 545 290 IG ½ " IG ½ " IG ½ "
5.3
Operation
Type
System volume
(100% water)
(m³)
System volume
(50% water)
(m³)
Working
pressure
(bar)
Permissible operating
gauge pressure
(bar)
Setpoint overflow
valve
(bar)
Operating
temperature
(°C)
30 1 – 0.5 – 3 8 – >0 – 70
30 GL – 2.5 0.5 – 3 8 – >0 – 70
