Vacuum spray degassing — 06.07.2016 - Rev. B English —
The device controller is shipped with the following default settings. Use the Customer menu to adjust these values to local conditions. In
specific cases, it is possible to further adjust the values in the Service menu.
Language EN Display language
Servitec Magcontrol For systems with diaphragm-type pressure expansion
tank
Minimum operating pressure p0 1.0 bar Only Magcontrol
Safety valve, pressure 3.0 bar Pressure value for the safety valve of the heat generator
in the system to trip
Next maintenance 12 months Time left to the next due maintenance
Floating alarm contact NO Only the messages marked in the message list
Makeup
Maximum makeup quantity 1000 Litres Only if controller with "With water meter yes"
Maximum makeup time 20 minutes Only Magcontrol
Maximum makeup cycles 3 cycles within 2 hours Only Magcontrol
Degassing
Degassing programme Interval degassing Continuous operation with degassing cycles
Continuous degassing time 5 hours Time of continuous degassing
Softening (Only if "With softening yes")
Lock makeup No Available soft ware capacity = 0
Hardness reduction 8°dH = Target – Actual
Maximum makeup quantity 0 Litres Attainable makeup quantity
Attainable water capacity
Cartridge replacement 18 months Replace cartridge
Makeup
Pressure differential, "NSP" makeup 0.2 bar Only Magcontrol
Pressure differential, filling pressure PF – P0
Degassing
Idling times between degassing intervals 23 hours Idling times between the degassing intervals
Number of degassing cycles for each
interval
n = 8 Number of degassing cycles in one interval
Daily start 08:00 h Start of the daily degassing intervals
