RefPlus EK Series - Page 14

R
14
INSTALLATION
A B A B
SUCTION LINE
TO COMPRESSOR
SUCTION LINE
TO COMPRESSOR
EVAP.
RED TEE
RED TEE
U-BEND OR
2 ELLS
45
O
STR.
ELLS
90
O
STR.
ELLS
EVAP.
Figure 8 Double suction riser
MULTIPLE EVAPORATORS
ON DIFFERENT LEVELS:
COMPRESSOR ABOVE
MULTIPLE EVAPORATORS
STACKED ON SAME LEVEL:
COMPRESSOR ABOVE
(ARRANGEMENT
A PREFERRED)
MULTIPLE EVAPORATORS ON
SAME LEVEL: COMPRESSOR
BELOW
DOUBLE RISER
WHEN
NECESSARY
DOUBLE RISER
WHEN
NECESSARY
MULTIPLE EVAPORATORS ON
SAME LEVEL: COMPRESSOR
ABOVE
A B C
D
Figure 9 Multiple evaporator suction line construction
