EVAPORATOR STARTUP REPORT FORM
12. EVAPORATOR START-UP REPORT FORM
IMPORTANT: This startup report form must be lled out, signed and sent to RefPlus for the warranty to be honoured.
1. GENERAL INFORMATION
JOB LOCATION: _____________________________________________________________________________________________________________________
_____
REFPLUS RJ No: CONTRACTOR NAME:
UNIT COOLER MODEL No.: SERIAL No.:
2. PRE-START-UP (Check each item when completed)

CHECK ALL ELECTRICAL CONNECTIONS AND TERMINALS FOR TIGHTNESS

CHECK ALL FAN MOTORS AND MOTOR MOUNTS FOR TIGHTNESS

CHECK DRAIN LINES AND DRAIN PAN FOR PROPER DRAINAGE

CHECK DRAIN LINE HEATER FOR PROPER OPERATION

VERIFY THAT ALL DEFROST CONTROLS ARE FUNCTIONING PROPERLY

CHECK ALL FLARE CONNECTIONS FOR TIGHTNESS

CHECK ALL MECHANICAL SEALS AND REFRIGERANT PIPING CONNECTIONS FOR TIGHTNESS

CARRY OUT PRESSURE TEST (PRESSURE/DURATION) PRESSURE : PSI DURATION: ____
EVACUATION (DURATION): ________ FINAL MICRON: _
UNIT COOLER DRAIN LINE TRAPPED OUTSIDE OF BOX:

YES

NO
3. START-UP
REFRIGERANT
REFRIGERANT TYPE (I.E. R448A)
ELECTRICAL

CHECK FAN MOTORS FOR PROPER ROTATION
MAIN POWER (DESIGN): __________V / ________ PH / _______Hz
MAIN POWER (MEASURED): L1-L2 __________V L1-L3 __________V L2-L3 __________V
CONTROL VOLTAGE (MEASURED): __________V
TOTAL UNIT AMPERAGE (MEASURED) __________ AMPS
FAN 1 __________ AMPS (L1) __________ AMPS (L2) _________ AMPS (L3) _________ AMPS (RATED)
FAN 2 __________ AMPS (L1) __________ AMPS (L2) _________ AMPS (L3) _________ AMPS (RATED)
FAN 3 __________ AMPS (L1) __________ AMPS (L2) _________ AMPS (L3) _________ AMPS (RATED)
FAN 4 __________ AMPS (L1) __________ AMPS (L2) _________ AMPS (L3) _________ AMPS (RATED)
FAN 5 __________ AMPS (L1) __________ AMPS (L2) _________ AMPS (L3) _________ AMPS (RATED)
TEMPERATURE START-UP AFTER 24 HOURS OF OPERATION
AMBIENT TEMPERATURE 0F 0F
DESIGN BOX TEMPERATURE 0F 0F
OPERATING BOX TEMPERATURE 0F 0F
SUPERHEAT AT COMPRESSOR 0F 0F
SUCTION LINE TEMP. AT EVAPORATOR 0F 0F
SUPERHEAT AT EVAPORATOR 0F 0F
SUB-COOLING 0F 0F
LIQUID TEMPERATURE 0F 0F
PRESSURES (in cooling mode)
REFRIGERANT SUCTION PSIG TEMP AT COMPRESSOR 0F
REFRIGERANT DISCHARGE PSIG TEMP AT COMPRESSOR 0F
