RefPlus EK Series - Eja-Lja-Dja Models - Air Defrost (Low-Speed Fan Motors)

R
28
13.7 TYPICAL WIRING DIAGRAM FOR ALL EJA-LJA-DJA MODELS - AIR DEFROST
LOW-SPEED FAN MOTORS - 208-230/3/60
BLACK
L2
L3
L1
RED
BLUE
L1
L2
L3
: OVERLOAD
BLACK
BROWN
ORANGE
ORANGE
YELLOW
YELLOW
U1
TB
TB
W2
M#
WHITE
BLUE
GRAY
BLACK
W1
V1
V2
U2
RED
BLUE
RED
PDB
: TERMINAL BLOCK
MMP: MANUAL MOTOR PROTECTERS
M#: FAN MOTOR
DETAIL "A" DETAIL "A"
M2
MMP
MMP
DETAIL "A"
LOW SPEED WIRING
208-230/3/60
BY OTHERS -----
M1
USE COPPER SUPPLY WIRES
WIRING DIAGRAMS
WIRING DIAGRAMS ARE FOR REFERENCE ONLY.
REFER TO DIAGRAM SUPPLIED WITH YOUR UNIT.
