13
Engine & Controls
DEPTH ALARM DEEP MODE
By pressing the “ON/OFF MODE” keypad again, the
deep depth alarm setting is displayed. is is the deepest
water that will energize the alarm. Press and hold the
up or down arrow keypads to adjust the reading to the
desired depth.
When the shallow depth setting is read by the depth
nder, the “SH” will ash on the LCD and the audible
alarm will sound in a rapid sequence. When the deep
depth setting is read by the transducer, the “DP” will
ash on the LCD and the audible alarm will sound at
two beeps per second.
To fully deactivate the alarm, reset it to zero. Pressing
the “ON/OFF MODE” keypad temporarily deactivates
the alarm. To reactivate, press the “ON/OFF MODE”
keypad until the depth reading appears.
KEEL OFFSET
By pressing the “ON/OFF MODE” keypad again, the
alarm will display the keel o set setting “KL”. It can
be set so the depth nder shows the depth below the
transducer, or the depth under the keel. Press the up or
down arrow keypads to adjust the reading to the desired
depth no further than 19.9 feet.
An example would be if the keel bottom is 3 feet below
the transducer, and you desire the depth sounder to
read the depth below the keel, the keel o set display
should be adjusted to 3.0 FT.
Once the keel o set is programmed, the shallow and
deep water alarms will be energized by the depth under
the keel.
UNITS
Pressing the “ON/OFF MODE” keypad again displays
the units mode “UN”. Press either the up or down
arrow keypads to set the units to feet (FT), meters
(M), or fathoms (F). Once these units are set, they will
remain the same for all modes. By pressing the “ON/
OFF MODE” keypad again, the depth nder will return
to the normal operations screen.
