27
Cosmetic Care & Maintenance
PLUMBING CONNECTORS
Plumbing connections to the blue fresh water lines
require special instructions when they are to be removed
or replaced. Be sure to turn o the fresh water helm
breaker.
To remove a tee, 90 degree, or straight connector tting
rst remove the cap on the end of the tting by using a
slotted screwdriver. Insert the screwdriver in the cap slot
and turn 90 degrees. Cap will release from the tting.
To reinstall a plumbing connection to a water line make
sure the line is cut o square and the end is smooth. is
will aid in ensuring a leakproof connection.
1. Install the cap on the supply line. You may need to use a
slotted screwdriver to remove the cap from a new tting.
2. Simply push the tting on to the supply line until
pressure is felt. is ensures it is completly in the tting.
3. Push the cap on the collar until it snaps in place.Turn
on the water pressure and check for leaks.
Note: With the connector in place, a movement between
the line and connector is normal.
2. Push the connector and collar together. Hold the
collar next to the connector with your nger. Pull and
the connector/collar will release itself from the water line.
Cap
Fitting
Hold End Of Fitting
With Fingers And Pull
Connector Free Of
Supply Line
Slotted
Screwdriver
To Next Page
