Equipment Operation
6-17
Digital Display Center Operation
When the battery charger is activated the following icons may appear
on the charger display:
1. The blue LED icon illuminates when power is initially connected.
2. The red battery type LED will illuminate for wet-cell batteries.
3. The green LED will illuminate indicating the self test and system
analysis was successful. This may take several minutes to complete.
4. The charge mode LED will illuminate for the following functions:
a. Charging- Red LED will fl ash during the self test (several minutes)
and will stay solid red during the charging cycle.
b. Conditioning- Amber LED illuminates during this mode.
c. Ready/Maintain- Green LED illuminates when system batteries are
fully charged.
d. Storage Recondition: Green LED fades back and forth when con-
ducting the once a month recondition mode. This would be benefi -
cial when in storage or at dockside for extended periods. Never leave
the extension cord engaged without proper ventilation since explosive
hydrogen gases will develop during the battery charging process. This
may apply to inside storage or moorings with the canvas installed.
e. Troubleshooting LED’s- A red LED illuminates indicating a prob-
lem with a system battery, DC connections, blown fuse, or AC system
connections.
For further information refer to the maintenance or troubleshoot-
ing section of this manual along with the vendors information in the
owner’s information packet.
